| 포트 수: | 2*4 듀얼 포트 | 핀 수: | 160 핀 |
|---|---|---|---|
| 커넥터 성별: | 여성 | 절연체 재료: | PBT |
| 접촉 핀 재료: | 형광 청동 | 현재 등급: | 1AMP |
| 내 전압: | 1 분 동안 500V | 절연체 저항: | 500mΩ min (DC500V) |
| 접촉 저항: | 최대 35mΩ | 작동 온도: | +105' Ｃ에 대한 -55' Ｃ |
| 전원: | AC 220V | 최소 채권 전력: | 1000V |
| 데이터 속도 속도: | 최대 4.25GB/s | 전송 속도: | 최대 10GB/s (SFP+) |
| 마치다: | 니켈 실버 | ||
| 강조하다: | 160P SFP connector stackable for data center,2x4 ports SFP connector press-fit,female SFP connector with press-fit design |
||
The SFP (Small Form-factor Pluggable) module connector supports various data speeds and is a primary optical transceiver for data communication. Introduced in the early 2000s to replace GBIC connectors, SFP connectors offer greater port density while handling up to 4.25Gb/s, making them ideal for fiber optic and Ethernet high-speed networking systems.
Compliant with IEEE 802.3 and SFF-8472 specifications, SFP connectors support Gigabit Ethernet, Fibre Channel, SONET, and other communication standards. The enhanced SFP+ version, introduced in 2006, supports data rates up to 10Gb/s while maintaining the same compact size.
| Product Name | SFP Connector |
| Product Line | Small Form-factor Pluggable |
| Connector Gender | Female Centronic Connector |
| Number of Positions | 160pin |
| Ports | 2×4 (8 Ports) |
| Contact Material | Phosphor Bronze |
| Finish | Nickel Silver |
| Insulation Material | PBT |
| Current Rating | 1AMP |
| Withstanding Voltage | 500V for one minute |
| Insulator Resistance | 500MΩ min (at DC500V) |
| Contact Resistance | 35MΩ Max |
| Operation Temperature | -55°C to +105°C |
Established in 2004, we specialize in IT and communication connectors including Centronic IDC, PCB DIP, solder type, V.35, D-SUB, SCSI, and RJ series connectors. Our UL- and SGS-certified products comply with RoHS Directive and maintain a defect rate below 0.5%.
Our 5,000 sqm ISO 9001:2008 and ISO 14001:2004 certified facility includes R&D, molding, plastic injection, stamping, and assembly production lines.
